Building a Custom Engine Agent with Vertex AI for Microsoft 365 Copilot

How to design a backend-owned Copilot agent and integrate Google Vertex AI cleanly across cloud boundaries.

Introduction

Extending Microsoft 365 Copilot often starts with declarative agents or lightweight plugins. That works well—until you need full control.

In this project, the goal was different:

keep orchestration inside a backend we fully own
integrate an external model provider (Google Vertex AI)
expose the result through Microsoft 365 surfaces like Teams and Copilot

This led to a Custom Engine Agent architecture, where:

Microsoft handles the channel.
Your backend owns the behavior.

This article focuses on two key areas:

how to structure a Custom Engine Agent properly
how to integrate Vertex AI as a first-class backend component

Why a Custom Engine Agent?

Instead of a declarative setup, the system is built as a backend-driven agent that can:

accept activities from Teams or Copilot
orchestrate prompt preparation in C#
call Vertex AI directly
persist generated assets and metadata
expose public download URLs
evolve independently of Microsoft 365 packaging

The key architectural decision:

Keep Microsoft 365 at the boundary — everything else is regular backend code.

High-Level Architecture


Copilot / Teams
        ↓
Custom Engine Agent host (Microsoft Agents SDK)
        ↓
Agent (activity → domain translation)
        ↓
Engine (use case logic)
        ↓
Orchestrator (prompt preparation)
        ↓
Vertex AI client
        ↓
Storage (assets + metadata)
        ↓
Response (image + URL)



Key design rule

Host → thin
Agent → channel-aware
Engine → business logic
Vertex client → provider integration

Project Structure


src/
  agents/
    AgentHost/
  infra/
    AppHost/
    ServiceDefaults/
  libs/
    Contracts/
    Engine/
    Infrastructure/
    Integrations.VertexAI/
    Orchestration/
    Prompts/
    Storage/
tests/
tools/



This separation enables:

independent backend testing
fast debugging
clear ownership of responsibilities

The Custom Engine Agent Host


var builder = WebApplication.CreateBuilder(args);
var requireAuth = builder.Configuration.GetValue<bool>("AgentSdk:EnableAuthentication");
builder.AddServiceDefaults();
builder.Services.AddHttpClient();
builder.Services.AddControllers();
builder.Services.AddProblemDetails();
builder.Services.AddCore(builder.Configuration, builder.Environment.ContentRootPath);
builder.AddAgentApplicationOptions();
builder.AddAgent<ImageAgent>();
builder.Services.AddSingleton<IStorage, MemoryStorage>();
builder.Services.AddA2AAdapter();
builder.Services.AddAgentAuthentication(builder.Configuration, requireAuth);
var app = builder.Build();
if (requireAuth)
{
    app.UseAuthentication();
    app.UseAuthorization();
}
app.MapAgentApplicationEndpoints(requireAuth);
app.MapA2AEndpoints(requireAuth);



The host also exposes HTTP endpoints like:

/images/generate
/images/edit
/assets/...

This allows testing without Teams, which is critical.

Translating Activities into Backend Logic


public sealed class ImageAgent : AgentApplication
{
    private readonly IImageGenerationEngine _engine;
    public ImageAgent(AgentApplicationOptions options, IImageGenerationEngine engine)
        : base(options)
    {
        _engine = engine;
        OnActivity(ActivityTypes.Message, OnMessageAsync);
    }
    private async Task OnMessageAsync(ITurnContext context, ITurnState state, CancellationToken ct)
    {
        var message = context.Activity.Text?.Trim();
        if (string.IsNullOrWhiteSpace(message))
        {
            await context.SendActivityAsync("Provide a prompt.");
            return;
        }
        var result = await _engine.GenerateImageAsync(
            new GenerateImageRequest(message), ct);
        await SendImageAsync(context, result, ct);
    }
}



The agent should stay thin. All real logic belongs in the backend.

The Engine Layer


public sealed class ImageGenerationEngine(
    IPromptWorkflowOrchestrator orchestrator,
    IVertexAiImageClient vertexClient,
    IAssetStorage storage)
{
    public async Task<GenerateImageResponse> GenerateImageAsync(
        GenerateImageRequest request,
        CancellationToken ct = default)
    {
        ValidatePrompt(request.Prompt);
        var prepared = await orchestrator.PrepareGenerateAsync(request, ct);
        var generated = await vertexClient.GenerateAsync(prepared, ct);
        var stored = await storage.SaveAsync(generated, ct);
        return new GenerateImageResponse(
            stored.AssetId,
            stored.AssetUri,
            stored.FileName,
            stored.ContentType);
    }
}



This is where the system becomes a real application, not just a bot.

Prompt Orchestration


public sealed class PromptWorkflowOrchestrator
{
    public Task<PreparedPrompt> PrepareGenerateAsync(
        GenerateImageRequest request)
    {
        var prompt = $"Create an image for prompt '{request.Prompt}'";
        var metadata = new Dictionary<string, string>
        {
            ["operation"] = "generate",
            ["style"] = request.Style ?? "default"
        };
        return Task.FromResult(new PreparedPrompt(prompt, metadata));
    }
}



This layer enables:

prompt policies
safety rules
future workflows

Deep Dive: Vertex AI Integration

This is the most critical boundary in the system.

Microsoft handles transport.
Vertex AI handles generation.
Your backend owns everything in between.

Design Goals

explicit integration (no hidden SDK magic)
full control over payloads
provider-agnostic interface
testable in isolation
cloud-neutral

Client Interface


public interface IVertexAiImageClient
{
    Task<GeneratedAsset> GenerateAsync(
        PreparedPrompt prompt,
        CancellationToken ct = default);
    Task<GeneratedAsset> EditAsync(
        EditImageRequest request,
        CancellationToken ct = default);
}



Endpoint Construction


private string GetGenerateEndpoint()
{
    return $"https://{_options.Region}-aiplatform.googleapis.com/v1/projects/{_options.ProjectId}/locations/{_options.Region}/publishers/google/models/{_options.Model}:predict";
}

Request Payload


public Task<GeneratedAsset> GenerateAsync(
    PreparedPrompt prompt,
    CancellationToken ct = default)
{
    var aspectRatio = prompt.Metadata.TryGetValue("aspectRatio", out var value)
        ? value
        : "1:1";
    var payload = new
    {
        instances = new[]
        {
            new
            {
                prompt = prompt.Value,
                negativePrompt = "low quality, blurry"
            }
        },
        parameters = new
        {
            sampleCount = 1,
            aspectRatio,
            seed = 1234
        }
    };
    return SendPredictRequestAsync(
        GetGenerateEndpoint(),
        payload,
        "generate",
        prompt.Value,
        ct);
}



Sending Requests


private async Task<GeneratedAsset> SendPredictRequestAsync(
    string endpoint,
    object payload,
    string operation,
    string sourcePrompt,
    CancellationToken ct)
{
    var credential = await CreateCredentialAsync(ct);
    var token = await credential.GetAccessTokenForRequestAsync();
    using var request = new HttpRequestMessage(HttpMethod.Post, endpoint);
    request.Headers.Authorization = new AuthenticationHeaderValue("Bearer", token);
    var json = JsonSerializer.Serialize(payload);
    request.Content = new StringContent(json, Encoding.UTF8, "application/json");
    using var response = await _httpClient.SendAsync(request, ct);
    if (!response.IsSuccessStatusCode)
    {
        var error = await response.Content.ReadAsStringAsync(ct);
        throw new Exception($"Vertex AI error: {error}");
    }
    var responseContent = await response.Content.ReadAsStringAsync(ct);
    return MapResponse(responseContent, operation, sourcePrompt);
}



Response Mapping


private GeneratedAsset MapResponse(string json, string operation, string sourcePrompt)
{
    using var doc = JsonDocument.Parse(json);
    var base64 = doc.RootElement
        .GetProperty("predictions")[0]
        .GetProperty("bytesBase64Encoded")
        .GetString();
    var bytes = Convert.FromBase64String(base64);
    return new GeneratedAsset
    {
        Content = bytes,
        FileName = $"{Guid.NewGuid()}.png",
        ContentType = "image/png",
        Provider = "VertexAI",
        SourcePrompt = sourcePrompt,
        Operation = operation
    };
}



Authentication


private async Task<GoogleCredential> CreateCredentialAsync(CancellationToken ct)
{
    if (!string.IsNullOrWhiteSpace(_options.CredentialsJson))
        return GoogleCredential.FromJson(_options.CredentialsJson);
    if (!string.IsNullOrWhiteSpace(_options.CredentialsJsonBase64))
    {
        var json = Encoding.UTF8.GetString(
            Convert.FromBase64String(_options.CredentialsJsonBase64));
        return GoogleCredential.FromJson(json);
    }
    return await GoogleCredential.GetApplicationDefaultAsync(ct);
}



Cross-Cloud Lesson

Local:

gcloud auth application-default login

✔ Works

Azure:

❌ Fails

Solution

VertexAi__CredentialsJsonBase64=...

Storage Layer


public async Task<StoredAsset> SaveAsync(GeneratedAsset asset)
{
    var id = Guid.NewGuid().ToString("n");
    var filePath = Path.Combine(_root, id, asset.FileName);
    await File.WriteAllBytesAsync(filePath, asset.Content);
    return new StoredAsset(id, $"/assets/{id}/{asset.FileName}");
}



Public URLs


public string ResolveAssetUrl(string uri)
{
    return $"{PublicOrigin}{uri}";
}

Deployment with Aspire


var builder = DistributedApplication.CreateBuilder(args);
builder.AddProject<Projects.AgentHost>("agent-host")
    .WithExternalHttpEndpoints()
    .WithHttpHealthCheck("/health");
builder.Build().Run();



Debugging Reality

At one point:

Playground ✅
Backend ✅
Teams ❌

Error

The tenant admin disabled this bot

Root Cause

Broken Azure Bot identity.

Fix

new App Registration
new Azure Bot
same backend

➡️ everything worked instantly

Key Takeaways

Custom Engine Agent = backend-first architecture
Vertex AI = explicit integration layer
Separate everything aggressively
Debug by layers, not assumptions

Final Thoughts

This approach shifts the model:

From:

“Copilot calls AI”

To:

“Copilot calls your system, which uses AI”

That difference is what enables:

control
reliability
extensibility

That’s all folks!

Cheers!
Gašper Rupnik
